SMD5050 regular RGBW led strip light

SMD 5050 Flexible RGB+W LED Strip Light

1. With this flexible LED strip, you can use it for your home, stage, bar decoration or you could also use our 2.4GHz RGBW Multi zone controller to control the LED strip.
2. The LED strips uses 12V DC or 24V, which is the common for the red, green, blue and White LED. To turn the light, just connect the respective pin to GND (0V). Example to turn on red, connect the ‘R’ input/pad to ground.
3. With RGB LED strips, you could create all sorts of color light by mixing the different RED, GREEN and BLUE intensity (brightness), and white color can adjust brightness according to the different environment. This can be easily done using RGB controller with some simple MOSFET circuit.
4. These strip can be used with our 2.4GHz RGBW Multi zone remote controller to allow you to display with different colors and different preset modes of lighting effects. Example, fading from one color to another.
5. 5050 SMD LED RGB+W Flexible Light Black or White Strips 10mm PCB, 30leds, 60leds, 72leds, 120leds are available.

Different PCB color are available

How to connect 4 In 1 5050 RGBW Flexible led strip light?

I. Cut along the light strip tape wherever a dashed line divides two sets of positive and RGBW connection points.

II. Peel away a portion of the light strip adhesive backing at one end. With the solderless clamp open to create two pieces of led strip, slide the strip end all the way into the solderless clamp. Close the hinged clamp.

III. You could also use our 2.4GHz RGBW Multi zone controller to control the LED strip, it could be used to create different color and adjust brightness.
