Product Features
- Silicone Ledline Flex Top1615 IP67, DC24V,has bending direction vertically and Front / Side / Bottom Cable Entry. with radius of 150mm (5.9” ) and across section size:16mm*15mm/0.63”*0.59”(W*H).
- It is IP67 protection, never yellow, UV resistant, saltwater resistant and high temperature resistant via opal silicone coating.Uniform luminance and dot free will bring the most excellent performance for indoor& outdoor application.
- The product has constant voltage and constant current version. Constant current version can connect 28 meters in series with one power supply and don’t have voltage drop, and can save the installation cost better.
- Unique end cap design, can install quickly and easily to meet the different length’s request, No welding and dealing with waterproof.
| Spec. | Description |
|---|---|
| Product Name: | 1615 – Top view silicone led neon flex IP67- 3 Years warranty |
| Item No.: | TY-N1615V24-Cx / TY-N1615V24-CCx |
| Size(mm): | 16*15mm |
| LED Type: | SMD2835 LED Chip |
| LED QTY(pcs): | 120LEDs/meter |
| IC Type: | / |
| IC QTY(pcs): | / |
| Pixels: | / |
| PCB Material: | Double side White FPC |
| Luminous Flux(lm): | 24-26lm/led |
| CIR(Ra): | >90Ra |
| Voltage(V): | DC24V |
| Watt(W): | 5W/10W/15W are available |
| Driving method: | Constant Voltage & Constant Current |
| Beam angle(°): | 120 |
| Available Color: | WW/NW/CW/Red/Yellow/Blue/Green/Ice Blue/Pink/Orange/RGB/RGBW |
| Color temperature (Kelvin): | 2100K/2400K/2700K/3000K/3500K/4000K/5000K/6000K |
| IP Rank: | IP67 |
| Warranty: | 3 years |
| Lifespan(hrs): | 50000Hrs |
| Packaging: | 5 meters, 10 meters, 15 meters, 20 meters, 50 meters/reel |
| Way of installation: | Stainless steel Mounting clips, Aluminium profile, Cured Metal profile |
| Sample lead time: | 3-5 days |
| Order lead time: | 5-7 days |
| Payment term: | T/T, Paypal, L/C, Western&Union |
Product Features
- Silicone Ledline Flex Top1615 IP67, DC24V,has bending direction vertically and Front / Side / Bottom Cable Entry. with radius of 150mm (5.9” ) and across section size:16mm*15mm/0.63”*0.59”(W*H).
- It is IP67 protection, never yellow, UV resistant, saltwater resistant and high temperature resistant via opal silicone coating.Uniform luminance and dot free will bring the most excellent performance for indoor& outdoor application.
- The product has constant voltage and constant current version. Constant current version can connect 28 meters in series with one power supply and don’t have voltage drop, and can save the installation cost better.
- Unique end cap design, can install quickly and easily to meet the different length’s request, No welding and dealing with waterproof.
- 16x15mm silicone led neon flex datasheet
- Tyria All size silicone led neon
| Product Name | IP Rank | Reel/CTN | CTN Size(cm) | N.W./Reel | G.W./CTN |
|---|---|---|---|---|---|
| 3528 flexible led strip, 30leds/meter | IP20 | 50 Reels | 52*24.5*27cm | 0.10kg | 5.8kg |
| 3528 flexible led strip, 30leds/meter | IP65 | 50 Reels | 52*24.5*27cm | 0.22kg | 10.0kg |
| 3528 flexible led strip, 60leds/meter | IP20 | 50 Reels | 52*24.5*27cm | 0.19kg | 6.0kg |
| 3528 flexible led strip, 60leds/meter | IP65 | 50 Reels | 52*24.5*27cm | 0.22kg | 11.5kg |
| 3528 flexible led strip, 60leds/meter | IP67 | 40 Reels | 52*24.5*27cm | 0.24kg | 10.1kg |
| 3528 flexible led strip, 120leds/meter | IP20 | 50 Reels | 52*24.5*27cm | 0.15kg | 8.0kg |
| 3528 flexible led strip, 120leds/meter | IP65 | 50 Reels | 52*24.5*27cm | 0.27kg | 14.0kg |
| 3528 flexible led strip, 120leds/meter | IP67 | 40 Reels | 52*24.5*27cm | 0.29kg | 12.1kg |
| 3528 flexible led strip, 120leds/meter | IP68 | 40 Reels | 52*24.5*27cm | 0.35kg | 14.5kg |
